Intel Based PC build
Components
|
india |
|
Buy link |
||
Processor |
INTEL CORE I5-10500 10TH GENERATION PROCESSOR |
₹20,399 |
|
|
|
Graphics card |
INNO3D GEFORCE RTX 2060 TWIN X2 6GB GDDR6 |
₹26,200 |
|
||
Motherboard |
Msi B460M PRO-VDH WIFI Motherboard |
₹10,999 |
|
|
|
RAM |
ADATA XPG SPECTRIX D41 8GB (8GBX1) DDR4 RGB 3000MHZ |
₹2,890 |
|
|
|
SSD |
GIGABYTE 256GB SATA M.2 PCIE SSD |
₹4,250 |
|
|
|
Hard disk |
WD BLUE 1TB HDD (WD10EZEX) |
₹3,290 |
|
|
|
PSU |
ANTEC ATOM B650 80 PLUS BRONZE 650 WATT POWER SUPPLY |
₹4,100 |
|
|
|
Cabinet |
Deepcool GamerStorm Macube 310P (White) |
₹5,826 |
|
|
|
Detail information of all components
INTEL CORE I5-10500 10TH GENERATION PROCESSOR (12M CACHE, UP TO 4.50 GHZ)
why we choose Intel because Intel is best for gaming and why is that because of Intel single core performance is good give more CPU power then AMD thatswhy is still best for gaming and productivity performance is good not very good as compare to AMD ryzen CPU
Series |
Core i5 (10th Gen) |
CORES |
6 Cores |
THREADS |
12 Threads |
SPEED |
3.1 GHz |
SPEED (TURBO) |
4.5 GHz |
CACHE |
12 MB |
MAX MEMORY SUPPORT |
128 GB |
INTEGRATED GRAPHICS |
Intel UHD Graphics 630 |
INCLUDED CPU COOLER |
Yes |
UNLOCKED |
No |
TDP |
65W |
WARRANTY |
3 Years |
BUY NOW
₹ 20,990 |
₹20,399 |
₹ 20,771.02 |
₹20,499 |
$202 |
|
$230.67 | |
|
|
Other Options or Alternative
Intel Core I5-10400 Processor
|
|
BUY NOW
₹ 20,900 | ₹17,999 | ₹ 19,103.63 | ₹18,999 |
$182 | $212.16 |
| |
Intel Core I5-9600KF
|
|
Series |
Core i5
(9th Gen) |
CORES |
6 Cores |
THREADS |
6 Threads |
Socket |
LGA1151 |
SPEED |
3.7 GHz |
SPEED
(TURBO) |
4.6 GHz |
CACHE |
9 MB |
MAX MEMORY
SUPPORT |
128 GB |
INTEGRATED
GRAPHICS |
None |
INCLUDED
CPU COOLER |
No |
UNLOCKED |
No |
TDP |
95W |
WARRANTY* |
3 Years |
BUY NOW
₹ 17,899 | ₹16,999 | ₹ 24,879.05 | ₹17,449 |
$203 |
| $321 | |
2. Graphics Card
INNO3D GEFORCE RTX 2060 TWIN X2 6GB GDDR6
|
|
Display Support |
Multi Monitor : Yes Maxmium Digital Resolution : 7680x4320
HDCP : 2.2 Standard Display Connectors : HDMI 2.0b, 3x
DisplayPort 1.4 InternalAudio Input for HDMI : Internal
Standard Graphics Card Dimensions: Length 196mm Height 113mm
Width 2-slot |
GPU Engine Specs |
CUDA Cores : 1920 Boost Clock (MHz) : 1680 |
MEMORY SIZE |
6GB |
Memory Specs |
Memory Clock : 14Gbps Standard Memory Config : 6GB Memory
Interface : GDDR6 Memory Interface Width : 192-bit Memory
Bandwidth (GB/sec) : 336 |
MEMORY TYPE |
GDDR6 |
SERIES |
RTX 2060 |
Accessories |
Driver CD Kit : Yes 3D Mark : Yes VR Mark : Yes |
Feature Support |
Real-Time Ray Tracing : Yes NVIDIA GeForce Experience : Yes
NVIDIA Ansel : Yes NVIDIA Highlights : Yes NVIDIA
G-SYNC™-Ready : Yes Game Ready Drivers : Yes Microsoft DirectX
: 12 Vulkan API : Yes OpenGL : 4.5 Bus Support : PCI-E 3.0 X16
OS Certification : Windows 7, 10, Linux, FreeBSDx86 |
CHIPSET |
NVIDIA GeForce |
Thermal and Power Spec |
Minimum System Power Requirement (W) : 500 Supplementary
Power Connectors : 8-pin |
|
|
Warranty |
3 Years |
BUY NOW
₹ 28,500 |
₹26,200 |
coming soon |
₹28,000 |
|
Other Options or Alternative
Galax RTX 2060 (1 Click OC) 6GB
|
|
MODEL |
26NRL7HPX7OC |
CHIPSET |
NVIDIA GEFORCE |
GPU |
RTX 2060 |
PCI EXPRESS |
3.0 |
GPU BASE CLOCK |
1365 MHz |
GPU BOOST CLOCK |
1695 MHz |
MEMORY CLOCK |
14 Gbps |
MEMORY SIZE |
6 GB |
MEMORY INTERFACE |
192-BIT |
MEMORY TYPE |
GDDR6 |
DIRECT X SUPPORT |
12 |
OPEN GL |
4.6 |
PORTS |
Display Port 1.4, HDMI 2.0b, DVI-D |
RESOLUTION |
7680x4320 |
COOLER |
Dual Fan |
DUAL-LINK DVI SUPPORTED |
Yes |
PACKAGE CONTENTS |
Graphics Card, User Manual |
GPU CORE (CUDA CORE) |
1920 |
POWER CONNECTORS |
1 x 8-pin |
|
|
Warranty |
3 Years |
BUY NOW
₹ 28,500 |
₹31,200 |
coming soon |
₹26,928 |
|
More.....
I. ASUS GEFORCE RTX 2060 PHOENIX EDITION 6GB GDDR6
BUY NOW
₹ 28,800 |
₹26,999 |
coming soon |
₹26,999 |
|
For other reason usa uk etc.
|
|
3. Motherboard
Msi B460M PRO-VDH WIFI Motherboard
|
|
*Highlight Feature
- Supports 10th Gen Intel® Core™ / Pentium® Celeron® processors for LGA 1200 socket
- Supports DDR4 Memory, up to 2933(Max) MHz
- Core Boost: With premium layout and digital power design to support more cores and provide better performance.
- DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability.
- Twin Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
- Audio Boost: Reward your ears with studio grade sound quality
- Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.
CPU |
Supports
10th Gen Intel® Core™ and Pentium® Gold / Celeron® processors for LGA1200
socket |
Chipset |
Intel®
B460 Chipset |
Memory |
|
Expansion Slot |
|
Onboard Graphics |
|
Storage |
|
USB |
|
RAID |
|
Audio |
Realtek® ALC892 Codec 7.1-Channel High
Definition Audio |
LAN |
1x Realtek®
RTL8111H Gigabit LAN Controller |
Wireless LAN &
Bluetooth® |
|
Internal connectors |
|
Back panel ports |
|
Form Factor |
mATX Form Factor 9.6 in. x 9.6 in.
(24.4 cm x 24.4 cm) |
Warranty |
3 Years |
BUY NOW
₹ 12,900 |
₹10,999 |
₹ 11,634.47 |
₹10,999 |
$99.99 |
|
$114.89 |
|
|
|
Other Options or Alternative
MSI MAG B460M MORTAR WIFI
|
|
*Highlight Feature
- Supports 10th Gen Intel® Core™ / Pentium® Celeron® processors for LGA 1200 socket
- Supports DDR4 Memory, up to 2933 MHz(Max)
- Enhanced Power Design: 12+1+1 Duet Rail Power System, Core Boost, DDR4 Boost
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
- 2.5G LAN with LAN Manager and Intel Wi-Fi 6 AX Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
- Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
- Pre-installed I/O Shielding: Better EMI protection and more convenience for installation
- Intel Turbo USB 3.2 Gen 1: Powered by Intel USB 3.2 Gen 1 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speeds
- Audio Boost: Reward your ears with studio grade sound quality
4. RAM
ADATA XPG SPECTRIX D41 8GB (8GBX1) DDR4 RGB 3000MHZ RAM
|
|
- Mesmerizing RGB lighting–supports software from major motherboard makers, fully customizable and programmable
- Armor-inspired design with a bright RGB LED strip
- Supports the new Intel X299 platform and implements baseline 3000MHz(via SPD settings)
- Fast clock speeds 3000MHz
- Superior power efficiency: 20% less draw than DDR3 (operating voltage decreased from 1.5V to 1.2V)
- Intel XMP 2.0 –more accessible overclocking
- 10-layer PCBs for excellent stability
- RoHS compliant
Model |
AX4U300038G16A-ST41 |
Memory Series |
XPG SPECTRIX D41 |
Color |
Titanium Gray |
Memory Type |
DDR4 |
Size |
8GB |
Kit Type |
8GBx1 |
Speed |
3000MHz |
Latency |
CL16-20-20 |
Voltage |
1.35V |
Warranty |
Lifetime |
I.Adata XPG Gammix D30 8GB (8GBX1) DDR4 3000MHz
II.Crucial Ballistix Sport LT 8GB (8GBx1) DDR4 3000MHz Red
|
|
BUY NOW
₹ 5,999 |
coming soon |
coming soon |
₹3,600 |
|
|
|
|
Gigabyte 256GB M.2
|
|
- Form Factor: M.2 2280
- Interface: PCI-Express 3.0 x2, NVMe 1.3
- Total Capacity: 256GB*
- Warranty: Limited 3-years
- Sequential Read Speed : up to 1200 MB/s**
- Sequential Write speed : up to 800 MB/s**
- HMB (Host Memory Buffer) supported
- TRIM & S.M.A.R.T supported
Interface |
PCI-Express 3.0 x2, NVMe 1.3 |
Form Factor |
M.2 2280 |
Total Capacity |
256GB |
NAND |
NAND Flash |
External DDR Cache |
N/A |
Sequential Read speed |
Up to 1200 MB/s |
Sequential Write speed |
Up to 800 MB/s |
Random Read IOPS |
Up to 80K |
Random Write IOPS |
Up to 150K |
Dimension (W x H x L) |
80 x 22 x 2.3 mm |
Mean time between failure (MTBF) |
1.5M hours |
Power Consumption (Active) |
Average : R : 2200mW ; W : 2100mW |
Power Consumption (Idle) |
50mW |
Temperature (Operating) |
0°C to 70°C |
Temperature (Storage) |
-40°C to 85°C |
Warranty |
3 Years |
Other Options or Alternative
Kingston A2000 250GB M.2 NVMe Internal SSD
|
|
6. Hard disk
WD BLUE 1TB HDD (WD10EZEX
|
|
- CAPACITY 1TB
- SERIES BLUE
- FORM FACTOR 3.5 INCH
- RPM 7200 RPM
Model number |
WD10EZEX |
Interface |
SATA 6 Gb/s |
Formatted capacity |
1,000,204 MB |
Advanced Format (AF) |
Yes |
Form factor |
3.5-inch |
RoHS compliant |
Yes |
Performance |
|
Data transfer rate (max) |
|
Buffer to host |
6 Gb/s |
Host to/from drive (sustained) |
150 MB/s |
Cache (MB) |
64 |
Rotational speed (RPM) |
7200 RPM Class |
Reliability/Data Integrity |
|
Load/unload cycles |
300,000 |
Non-recoverable read errors per bits read |
<1 in 10 |
Limited warranty (years) |
2 Years |
For more Detail or BUY NOW
₹ 3,847 |
₹3,290 |
coming soon |
₹3,377 |
|
$55 |
|
$51.92 |
|
|
|
Other Options or Alternative
Seagate 1TB Barracuda 7200 RPM
|
|
7. PSU
ANTEC ATOM B650 80 PLUS BRONZE 650 WATT POWER SUPPLY
|
|
- 80 PLUS® BRONZE Certified - To reduce your electricity bill.
- CircuitShield™ - Industrial grade protections: OPP/OVP/UVP/SCP
- 120mm Silent Fan
- FLAT Cable
- Thermal Manager - An advanced fan control for optimal heat & noise management.
- Active Power Factor Correction (APFC)
- 3-Year Warranty
For more Detail or BUY NOW
₹ 4,929 |
₹4,100 |
coming soon |
₹4,150 |
|
|
|
|
|
8. Cabinet
1.Deepcool GamerStorm Macube 310P (White)
2.Circle Eliminator X1 Red LED (Black)
|
|
3.Fingers RGB-Flow C2 With SMPS (Black)
|
|
4.AeroCool Bolt RGB (Black)
|
|
5.THERMALTAKE VERSA N24
|
|
